WIMAG Pipe Suspension Grab

Indispensable pipe suspension grab for transport and pipe laying.
Reliable, no accidents, no damages.
Contact surface of clamp is steel/serrated.

  • Gripping depth extended from 220 mm to 260 mm.
  • Clamping range 90-200 mm (with rubber coating 50-150 mm).
  • Simple and fast adjustment of the clamping range via threaded spindle.
  • Gripping surfaces are grooved to prevent load slip.
  • Rubber-lined clamps on request.
  • Type 200D for prefabricated manholes according to DIN 4032 Part 1 with socket end for axial seal.
  • Can also be used acc. to DIN 4032 Part 2.
  • Other Wimag types according to DIN 4032 Part 2.
  • Can be delivered with longer chains.
  • Material: Clamp made of hollow sections, therefore torsion resistant and very light. Highstrength chains DIN 5687-5.
