General: During forklift work, there is often a need to lift at one point, using both forks and the full capacity of the fork lift. Our fork lift beam provides a simple solution as it can quickly be attached to the forks without the need for any mechanical locking. A stand to facilitate collection and return of the beam (storage) can be made to order.
Design: Cut plate with welded support plates. Friction rubber underneath the plates prevents sliding during loading. Model 6702 incorporates large openings for trucks with stabilizer legs. The beam comes complete with shackle and swivel safety hook.
Proof: Batch proof 2 x WLL

  • Material: High-strength structural steel.
  • Marking: Maximum load and CE-markning.
  • Finish: Yellow painted.
Part Code Code WLL
ton
Shackle code Hook (*) code (*) A
mm
B
mm
G
mm
H
mm
L
mm
Weight
kg
CAD
13.356700020 6702 2 1,236 WSB/S-7/8-10 92 220 50 340 180 7
13.356700030 6703 3 1,237 WSB/S-10-10 72 165 100 385 450 12
13.356700050 6705 5 1,128 WSB/S-13-10 72 165 100 425 450 16
13.356700080 6708 8 1,129 WSB/S-16-10 92 200 120 535 550 60

Other dimensions and designs are made on request.
(*) or equivalent

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
