Ringsplit pic
Ringsplit dwg
Part Code Diameter
mm
c
mm
f
mm
l
mm
Weight
kg/100pc
CAD
11.56SSP045 4.5 34 3,4 40 2
11.56SSP050 5 41 3,4 40 2.18
11.56SSP060 6 41 3,4 40 2.8
11.56SSP080 8 41 3,4 40 3.5
11.56SSP090 9 41 3,4 40 3.8
11.56SSP100 10 41 3,4 40 4.4
11.56SSP110 11 41 3,4 40 5.72

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
Download
